Product Summary

The AQY214EHAX (4 pin DIP) is a High cost-performance DIP4-pin type PhotoMOS relay with reinforced insulation. It is ideal for: (1)Modem; (2)Telephone equipment; (3)Security equipment; (4)Sensing equipment.

Parametrics

AQY214EHAX absolute maximum ratings: (1)LED forward current, IF: 50 mA; (2)LED reverse voltage, VR: 5 V; (3)Peak forward current, IFP: 1 A at f = 100 Hz, Duty factor = 0.1%; (4)Power dissipation, Pin: 75 mW; (5)Load voltage (peak AC), VL: 400 V; (6)output Continuous load current (peak AC), IL: 0.12 A; (7)output Peak load current, Ipeak: 0.3 A at 100ms (1 shot), VL= DC; (8)Power dissipation, Pout: 500 mW; (9)Total power dissipation, PT: 550 mW; (10)I/O isolation voltage, Viso: 5000 V AC; (11)Temperature limits: Operating, Topr: –40℃ to +85℃ –40°F to +185°F at Non-condensing at low temperatures; storage, Tstg: –40℃ to +100℃ –40°F to +212°F.

Features

AQY214EHAX features: (1)Reinforced insulation of 5,000 V; (2)Controls low-level analog signals; (3)High sensitivity and low onresistance; (4)Low-level off state leakage current of max. 1 μA.

Diagrams

AQY214EHAX circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AQY214EHAX
AQY214EHAX
Panasonic Electric Works
Solid State Relays 400v 120mA DIP Form A Norm-Open
Data Sheet
0-1000: $1.17
1000-3000: $1.14
3000-5000: $1.07
