Product Summary
The LH1525AABTR 1 Form A Solid-State Relay is a SPST normally open switch (1 form A) that can replace electromechanical relays in many applications. The LH1525AABTR requires a minimal amount of LED drive current to operate, making it ideal for battery powered and power consumption sensitive applications. The LH1525AABTR is constructed using a GaAIAs LED for actuation control and an integrated monolithic die for the switch output. The LH1525AABTR is ideal for: (1)General telecom switching; (2)Battery powered switch applications; (3)Industrial controls; (4)Programmable controllers; (5)Instrumentation.
Parametrics
LH1525AABTR absolute maximum ratings: (1)LED input ratings: continuous forward current, IF: 50 mA; (2)LED input ratings: reverse voltage, VR: 8 V; (3)Output operation (each channel): DC or peak AC load voltage, IL ≤ 50 μA, VL: 400 V; (4)Continuous DC load current, bidirectional operation pin 4 to 6, IL: 125 mA; (5)Continuous DC load current, unidirectional operation pins 4, 6 (+) to pin 5 (-), IL: 250 mA; (6)Ambient operating temperature range, Tamb: - 40 to + 85 ℃; (7)Storage temperature range, Tstg: - 40 to + 150 ℃; (8)Pin soldering temperature, t = 10 s max, Tsld: 260 ℃; (9)Input to output isolation test voltage, t = 1 s, VISO: 5300 VRMS; (10)Power dissipation, Pdiss: 550 mW.
Features
LH1525AABTR features: (1)Extremely low operating current; (2)High speed operation; (3)Isolation test voltage 5300 VRMS; (4)Current limit protection; (5)High surge capability; (6)DC only option; (7)Clean bounce free switching; (8)Low power consumption; (9)Surface mountable.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LH1525AABTR |
Vishay Semiconductors |
Solid State Relays Normally Open Form 1A |
Data Sheet |
|
|
||||||||||||
