PAA110

PAA110, dual normally open (1-Form-A), Solid State Relay, 400V, 150mA, 22Ω, 8-SMD

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.20~1.50

PartNumber:: PAA110

Brand:: Clare, Inc. - CLARE | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. DAVE's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-29

From Other Seller

Part Number:PAA110
US $1.20 - 1.50
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PAA110 is a 400V, 150mA, 22Ω, dual normally open (1-Form-A) optically isolated Solid State Relay. Its efficient MOSFET switches and photovoltaic die use Clare patented OptoMOS architecture to provide 3750Vrms of input to output isolation. The optically coupled output is controlled by a highly efficient GaAIAs infrared LED. The PAA110 is ideal for: (1)Telecommunications; (2)Instrumentation; (3)Medical Equipment-Patient/ Equipment Isolation; (4)Security; (5)Aerospace; (6)Industrial Controls.

Parametrics

PAA110 absolute maximum ratings: (1)Blocking Voltage: 400 VP; (2)Reverse Input Voltage: 5 V; (3)Input Control Current: 50 mA; Peak (10ms): 1 A; (4)Input Power Dissipation: 150 mW; (5)Total Power Dissipation: 800 mW; (6)Isolation Voltage, Input to Output: 3750 Vrms; (7)Operational Temperature: -40 to +85 ℃; (8)Storage Temperature: -40 to +125 ℃.

Features

PAA110 features: (1)3750Vrms Input/Output Isolation; (2)Small 8-Pin Package; (3)Low Drive Power Requirements (TTL/CMOS Compatible); (4)High Reliability; (5)Arc-Free With No Snubbing Circuits; (6)VDE Compatible; (7)FCC Compatible; (8)No EMI/RFI Generation; (9)Machine Insertable, Wave Solderable; (10)Surface Mount and Tape Reel Version Available.
